समकोण 3 पिन माइक्रो स्विच
माइक्रो स्विच में छोटे कॉन्टैक्ट गैप और स्नैप -एक्शन मैकेनिज्म की सुविधा है, यह निर्दिष्ट यात्रा और ऑपरेशन फोर्स द्वारा सक्रिय होता है, इसमें शेल कवर होता है, बाहर की ओर एक एक्ट्यूएट आर्म होता है, इसे लिमिट स्विच भी कहा जाता है।
विवरण
Micro switch features small contact gap and snap-action mechanism,it actuates by specified travel and operation force,there has shell cover it,the outside has a actuate arm,it also called as limit switch.
This is the three-pin terminal micro switch super small size for substrate mounting ,it calls micro limit switch or micro snap action switch,it has the left and right side terminal options,the tiny size and light weight makes it has numerous potential applications,there has low energy and power-duty electrical ratings allow the micro switch to be specified in many types filed,it also provides a variety of actuators,terminations,the high reliability makes it has more applications in kinds of fields.
विशेषताएं और लाभ
1. Improving the component SMT mount density of PCB board
2. Suitable for the reflow soldering
3. High reliability and sealed construction contact
4. Against electric ground terminal
5. Reel packing method
मूल जानकारी
विद्युत मूल्यांकन | 1ए 125वी एसी 3ए 125वी एसी |
विद्युत जीवन | 10,000 चक्र |
यांत्रिक जीवन | 1,000,000 चक्र |
ऑपरेशन फोर्स | 110±30gf |
तापमान | -25-125 |
आकार | 12.85.86.5मिमी |
मद | पीसीबी टर्मिनल समकोण माइक्रो स्विच |
माइक्रो स्विच के टिप्स
OF is operation force, the press force from free position drive to actuator
RF is releasing force,it's force from total position operates to original position
PT is pre-travel, it's move distance from actuator free position to actuation position
एफपी फ्री पोजीशन है, यानी बिना किसी एक्चुएशन फोर्स वाली पोजीशन।
अनुप्रयोग
Right Angle PCB Terminal Bent Feet Micro Switch are utilized in numerous potential applications,such as home appliance ,communication equipment,portable devices,peripheral products,electromechanical timers,vending machines,instrumentation and other digital products.
एफवीविन इलेक्ट्रॉनिक्स
The FVWIN was founded in 2013. The main activities — is the supply of electronics switches and sockets as well as connectors, a variety of illuminated switches, power socket ,USB connector ,XLR connectors and the provision of services for the production of PCB and contract manufacturing of electronic products.Our products covers a wide range of audio and video equipment,instruments,medical equipment,home appliance,security equipment,etc
